Camlock DC
Product Details
Zhejiang Leadtek Fluid Technology Co., Ltd. is one of the most experienced manufacturers and suppliers of camlock dc in China. Please feel free to buy customized camlock dc at competitive price from our factory. Also, free sample is available.
The professional manufacturer of camlock stainless
Item No:
The Camlock dc can be used with A type, E type, and F type adapters to seal the connecting ends. The camlock stainless DC type dust cover is a convenient Camlock female coupling cover device. This dust cover is typically used to cover and protect the coupling from dirt, dust, and moisture when not in use. This helps keep the coupling clean and ready for use, extending the system's lifespan and reducing maintenance. The Camlock dc type dust cover is compatible with all Camlock DC 200 female couplings of the same size.
The camlock dc200 is an indispensable component in the manufacturing and maintenance of machinery, automobiles, and other various equipment. These small but crucial parts are used to protect sensitive mechanical parts, preventing contamination from dust, dirt, and other debris, thus avoiding severe damage or failure.
The main advantage of the Camlock dc type dust cover is its ease of use. Simply push the cam arm down to securely attach the dust cover, forming a safe and reliable seal. This allows the installation and removal of the dust cover in just a few seconds, without the need for any additional tools. This saves time and makes it an efficient solution for applications that require quick changes. The DC type Camlock dust cover comes in various sizes, ensuring there is one suitable for your application. This makes it a popular choice across industries.
product features
The handle of Camlock B is designed by our factory and has been patented. This handle reduces labor during the connection process.
Based on customer requirements, we will provide a Mill Test report before shipment. Our SS304 and SS316 thread standards comply with ASTM A351/A351M standards.
The 304 or 316 camlock stainless couplings have excellent pressure resistance, making them suitable for various industrial applications.
For safety, the operating pressure is PN16, and the temperature range is -20°C to 100°C.
Camlock DC Manufacturer Advantages
Good Hygienic Performance
The surface of the Camlock dc type is smooth, highly resistant to contamination, and easy to clean and disinfect.
100% Connection and Disconnection Testing
We ensure that our Camlock products meet standards and can be matched with other Camlock couplings or couplings made from other materials.
Two Models Available
We offer two types of Camlock molds for you to choose from: one is heavy-duty, and the other is medium-duty.
Responsible After-Sales Service
Leadtek is a professional and responsible manufacturer. We take full responsibility for any quality issues.
Product Applications
The Camlock dc type has become a versatile solution for sealing hoses, pipelines, and tanks across various industries, including:
● Transportation and Logistics: Protecting tanker trucks and container connections.
● Agriculture and Irrigation: Preventing dirt or water from entering the pipelines.
● Chemical and Food Industries: Providing hygienic seals.
● Construction and Industry: Preventing dust and other particles from entering pipeline systems.
How to Use:
● To connect, slide the DC type coupling onto the male adapter and close the two cam arms.
● To disconnect, lift the cam handle and detach the two fittings.
Installation:
● Slide the female Camlock and grooved dust cover onto the male adapter and then close the two cam arms.
● The coupling part will then connect with the male fitting coupling.
Dimension Of camlock stainless
|
Size |
DN |
ΦD mm |
ΦD1 mm |
H mm |
H1 mm |
L mm |
L1 mm |
N.W. kgs |
|
1/2" |
15 |
31.8 |
24.4 |
38.2 |
29.2 |
50 |
166.8 |
0.126 |
|
3/4" |
20 |
39.9 |
32.5 |
42 |
31.5 |
58 |
174.8 |
0.161 |
|
1" |
25 |
45.7 |
37.2 |
49.1 |
37.1 |
69 |
195.1 |
0.23 |
|
1-1/4" |
32 |
55.5 |
46.1 |
56.5 |
43 |
85 |
234.9 |
0.328 |
|
1-1/2" |
40 |
63.4 |
54 |
58.5 |
43.5 |
92.5 |
242.4 |
0.367 |
|
2" |
50 |
74 |
63.6 |
65 |
48.5 |
102 |
251.9 |
0.483 |
|
2-1/2" |
65 |
87.8 |
76.4 |
69 |
51 |
114.5 |
264.4 |
0.658 |
|
3" |
80 |
104.5 |
92.3 |
74 |
54.5 |
139.5 |
305.8 |
1.005 |
|
4" |
100 |
133.5 |
120.3 |
77 |
56 |
168 |
334.3 |
1.364 |
Specification Of camlock dc200
|
Product Type |
Camlock DC |
|
Size |
1/2"-6"(DN15-DN150) |
|
Material |
SS304 (CF8), SS316 (CF8M) |
|
Pressure |
Class 150 |
|
Temperature |
-20℃ to +100℃ |
|
Application |
The food and beverage industry; The pharmaceutical industry; The oil and gas industry; The hydraulic system; The car repair and maintenance; |
|
Design Standard |
API 608 |
|
Technics |
Cast |
|
Inspection |
Thread test; Pressure leaking test; Visual inspection; |
|
Customized Support |
OEM, ODM, OBM |
|
MOQ |
No MOQ for our stock products |
|
Certificate |
ISO9001, ISO14001, ISO45001, CE, ROHs, KC, TS, etc.. |
