Stainless Steel Flanged Gate Valve

The Flange End Gate Valve utilizes a rising stem gate structure to precisely control the flow of fluids through vertical motion. The wedge-shaped gate (elastic seat design) offers bidirectional sealing, making it ideal for straight pipelines, with advantages such as simple structure, flexible operation, and low flow resistance.

Send Inquiry

Product Details

Stainless Steel Flanged Gate Valve – Professional Design and Manufacturing

Item No:

Applicable Media

✔ Industrial Fluids: Steam, compressed air, oils

✔ Municipal Networks: Tap water, wastewater, seawater

✔ Energy Transport: Natural gas, coal gas (non-corrosive)

Get A Free Sample

Stainless steel flanged gate valve Applicable

Stainless Steel Flanged Gate Valve Key Features

✔ Simple Structure – Easy to manufacture and maintain

✔ Flexible Operation – Full opening/closing of the gate, easy to operate

✔ Low Flow Resistance Design – Clear flow path when fully open, minimizing pressure loss

✔ Bidirectional Sealing – Suitable for bi-directional fluid flow

Product Advantages

✅ Low Maintenance Costs – Simple structure, easy replacement of parts

✅ Wide Media Compatibility – Compatible with clean water, wastewater, oils, and more

✅ Energy Efficient – Low flow resistance reduces transport energy consumption

✅ Safe and Reliable – Strong sealing performance, low leakage risk

Stainless Steel Flanged Gate Valve Product Advantages

flanged gate valve dimensions and Technical Parameters

Type	Stainless Steel Flanged Gate Valve
Size	½"~6" (DN15-DN150)
Material	SS304 / SS316
Pressure	PN16
Temperature	-20°C~+120°C

Dimension of Stainless Steel Flanged Gate Valve

flanged gate valve dimensions

Size	L mm	D1 mm	C mm	g mm	T mm	t mm	H mm	W mm	n-φ
1/2"	130	95	65	45	14	2	200	120	4-14
3/4"	150	105	75	55	14	2	200	120	4-14
1"	160	115	85	65	14	2	220	140	4-14
11/4"	180	135	100	78	16	2	260	160	4-18
11/2"	200	145	110	85	16	3	280	180	4-18
2"	250	160	125	100	16	3	310	240	4-18
21/2"	265	180	145	120	18	3	355	240	4-18
3"	280	195	160	135	20	3	380	280	8-18
4"	300	215	180	155	20	3	425	300	8-18
