3 Way Stainless Steel Ball Valve

The L-type 3 way stainless steel ball valve is a type of valve used for controlling the flow direction of fluids. Its characteristic is that the center of the ball is at an angle to the main pipeline axis, and the ball has three passages, including a main passage and two branch passages. When the ball rotates, it can control the fluid connection and direction between the two branch passages and the main passage. L-type 3 way ss ball valves typically use a double-seat sealing structure and are suitable for scenarios that require changing fluid flow directions.

L-type stainless 3 way valves are widely used in situations where fluid flow direction needs to be changed, such as in the oil, chemical, pharmaceutical, and food industries. They can control the flow of cold and hot fluids in air conditioning systems and can also mix different fluids together in process flows. Especially in the chemical, pharmaceutical, and food industries, L-type three-way ball valves can mix different fluids in specific proportions, which is very useful in many applications.
